32PM : Auto Cold Press

AUTO COLD PRESS : 32PM

Automatic Cold Press for green compacting impregnated segment or metal powders, designed to be fitted upon diamond saw blades and tools.

Automatic Cold Press for green compacting impregnated segment or metal powders, designed to be fitted upon diamond saw blades and tools.



Techinical Data

- MAX.POWER CONSUMPTION   :      9.5 KVA

- COMPRESSION FORCE      :    FROM 1500 TO 32,000 KG

- AIR PRESSURE SUPPLY:                6-8 BARS

- WATER REQUIREMENT:        10 LITERS /MIN.

- WEIGHING RANGE:            0.50 TO 50 GRAMS.

- WEIGHING TOLERANCE :      0.02 GRAMS PER WEIGHING

- OVERALL DIMENSIONS :  LENGHT:2000 mm WIDTH :1000 mm HEIGHT:1900 mm

- WEIGHT(INDICATIVE):          1200 KG

Special Modification

  1. Special screw system to feed regular quantity of powder to avoid bridge phenomenon.
  2. We made direct feeding channel in the dosing unit,which reduce weighing time of powder in the powder container.
  3. Moving car from dosing unit ,which was separated from funnel gives us better leveling of powder in the mould which positioned above mould in the previous system,was modified to put together with funnel,which located under moving car moving together.
  4. we modified mould size to be matched with any other compmay mould size.

Note

  • PERFORMANCE INFORMATION MAY BE USED ONLY AS GUIDE FOR PRODUCTION CAPACITY ESTIMATION OF COLD PRESS MACHINE.
  • VARIATIONS IN MATRIX POWDERS CAN INFLUENCE POSITIVELY OR NEGATIVELY UP TO 20% THE PRODUCTION CAPACITY OF COLD PRESS MACHINE.
